Description
200mm 3 Aspects Metro Traffic Signal Head
Retrofit design ＆ UV stabilized shell
Wide viewing angles& low power consumption
Even brightness ＆ standard chromatogram
Compatibility with most traffic housings and controllers
|
Description |
Distribution of |
Dimension(mm) |
Housing |
Housing Color |
Weight (kg) |
|||
|
200mm traffic head |
Horizontal +/-30° |
810 X 288 X 139 |
PC |
Black |
7.5 |
|||
|
Color |
Diameter |
Typical Wavelength |
Power Factor |
Impact Resistance |
Luminous |
Turn on/off time |
Voltage |
Rated Power |
|
Red |
Φ200mm |
626nm |
>90% |
IR3 |
>100cd |
≤75ms |
120vac-230vac |
8w |
|
Yellow |
Φ200mm |
592nm |
>90% |
IR3 |
>100cd |
≤75ms |
120vac-230vac |
8w |
|
Green |
Φ200mm |
505nm |
>90% |
IR3 |
>100cd |
≤75ms |
120vac-230vac |
8w |
