300mm Red Yellow Green Three Digital Countdown Timer Traffic Signals

  • Product Item：
  • Model: countdown timer
  • 5mm LEDs
  • 3 digital countdown timer
  • pixel look LEDs
    • green arrow light  , red cross light  , red cross green arrow light  , 3 Digital Countdown Timer traffic light
    Inquiry Send Email

    Description

    300mm Red Yellow Green Three Digital Countdown Timer Traffic Signals



    For the yellow digital, the maximum display digital is 9.

    The first one or two cycles are for memorizing time. The countdown function starts from the second or third cycle.

    When the red digital displays, the car should stop moving. The maximum display digital is 199.

    When the green digital displays, the car can move forward the street. The maximum display digital is 199.




    Description

    		Housing material

    Packing Size(cm)

    IP Grade

    Visor material

    Weight (kg)

    countdown timer

    		Polycarbonate

    2pcs in 1ctn, 40*40*45

    IP55

    Polycarbonate

    5/pcs

    Model

    		Color

    Power Factor

    LED quantities

      Operation

    Temperature

    Turn on/off time

    Voltage

    Rated Power

    Countdown modules

    (188)

    Red

    >90%

    90pcs

    -40°F~+165°F

    ≤75ms

    90vac-240vac

    8w

    Countdown modules

    (8)


    Yellow

    >90%

    		39pcs

    -40°F~+165°F

    ≤75ms

    90vac-240vac

    6w

    Countdown modules

    (188)



    		Green >90%
    		 90pcs
    		 -40°F~+165°F
    		 ≤75ms
    		 90vac-240vac 8w
